Lots
Lot 138: HURCO Hawk 20 Milling Machine with Hurco UltiPath Control
Table size 1270mm c 254mm. Long travel 863mm. Cross travel 356mm. Spindle speeds 50-3750 rpm (inf.var). Powered Drawbar. Safety guarding.
Closed Lots
Lot 1: CORREA FP30-30 CNC Gantry Mill with Heidenhain TNC426 Control. Year 2002
Table dimensions 3000mm x 1250 mm. Number of T slots 8. T slots dimensions 22 mm. X axis traverse 2500 mm. Y axis traverse 1800 mm. Distance between columns 1680 mm. Z axis traverse 800 mm. Head Type Standard vertical spindle. Tool clamping system Hydraulic. Spindle Taper ISO 50. Speed Range 20-2000 rpm. Spindle power 22 kW. Feedrates 2-5000mm/min. Rapids 15000/12000 mm/min. Maximum weight on table 10,000 kg. External Guarding.Universal Milling Head. Coolant. Manual Toolchange. Machine dimensions 7300mm x 2690mm x 3400mm. Machine Weight 21,500 kg.
Lot 1: 3 tonne Overhead Crane with Crane Rail and 10 x Stanchions
Single Beam KONE Hoist Type Overhead Crane. 3tonne Capacity.
Year of Manufacture 2017
24ft span from centre wheel to centre wheel
Total length 25ft
Total width 10ft
Complete with 10 x Steel Stanchions and Rail
Lot 1: DOOSAN VT1100M Turning Centre with Fanuc 0iTF Control. Year 2023
Swing over bed 1270mm. Swing over saddle 1000mm. Maximum turning
diameter 1100mm. Maximum turning length 960mm. Maximum workpiece
weight (incl. chuck) 2,200kg. Spindle nose 702-4-NO.15. Spindle max
power 65 / 55 / 45kW. Spindle max torque 7,552Nm. Spindle speed
maximum 850rpm. Integral box guideway construction. X axis travel
580mm. Z axis travel 1,000mm. C axis travel 360deg. X axis rapid
traverse 20m/min. Z axis rapid traverse 20m/min. C axis rapid
traverse 14r/min. Type BMT85P. Number of stations 12. OD tool size
32mm square. Boring bar size 80mm diameter. Rotary tool power
7.5/11.0kW. Rotary tool speed 3000rpm. Rotary tool collet size ER50
(6-32mm diameter). Power requirements 98.77kVA.
Additional Accessories
Swarf Conveyor MH500 type (rear exit). Swarf bin. FSE 70 bar NOP
pump upgrade for switchable duty 3 pressures: 20, 40 and 70 bar
(back pressure) via M code. Coolant chiller. Operator working
platform. Coolant wash gun. Renishaw OLP40 inspection probe.
Filtermist FX7002F oil mist separator with F Monitor 2.
HC40G Samchully Closed Centre Chuck including 1 set of hard jaws
& 1 set of soft jaws. 2 off Face type toolholder (R78935). 2
off Cross type toolholder (R78756A).
Compete with a selection of 8 x unused live tooling
Dimensions L x W x H 2830mm x 3305mm x 4012mm. Weight
22,550kg.
550 Cutting Hours
